Tradespeople navigating city traffic. Couriers delivering pallets on tight schedules. Builders hauling everything from piping to plasterboard. Even removal companies relocating entire homes. The Vauxhall Movano is engineered for those who need their van to shoulder the heavy lifting — literally and figuratively.
With its 2025 update, the Movano remains one of Britain’s most versatile large vans, offering an unparalleled blend of payload, loadspace, and cost-effectiveness. From the nimble L1H1 – ideal for city driving – to the cavernous L4H3, there’s a configuration to fit nearly every requirement.
This guide brings together every detail: full Vauxhall Movano dimensions, carrying capacity, and buying advice — all clearly laid out for both desktop and mobile users. If you’re short on time but need all the key facts, our tables and diagrams keep everything just a tap away.
Quick Reference Table: Movano Dimensions & Load Area
Before you dig into specifics, here's a high-level glance at how each variant stacks up. All measurements are in millimetres or cubic metres as indicated.
Model
Ext. Length
Ext. Height*
Loadspace Length
Loadspace Height
Max Width
Volume (cu m)
Payload (max, kg)
L1H1 FWD
5,048
2,307
2,583
1,700
1,765
7.8
1,620
L1H2 FWD
5,048
2,500
2,583
1,894
1,765
8.6
1,598
L2H2 FWD
5,548
2,500
3,083
1,894
1,765
10.8
1,529
L2H3 FWD
5,548
2,749
3,083
2,144
1,765
12.3
1,500
L3H2 FWD
6,198
2,488
3,733
1,894
1,765
13.0
1,431
L3H3 FWD
6,198
2,744
3,733
2,144
1,765
14.8
1,424
L3H2 RWD
6,198
2,527
3,733
1,798
1,765
13.0
2,148
L3H3 RWD
6,198
2,786
3,733
2,048
1,765
14.8
2,125
L4H2 RWD
6,848
2,557
4,383
1,798
1,765
14.9
2,108
L4H3 RWD
6,848
2,808
4,383
2,048
1,765
17.0
2,037
*Heights vary depending on front or rear-wheel drive (FWD/RWD); check narrative below for specific details.
Mobile users: swipe the table to see the full range, including interior sizes and payload. For full specifications, a printable PDF is available at the end of this guide.
Movano Exterior Dimensions by Model (L1H1–L4H3)
Whether you're parallel parking in the city or moving loads across the country, the Movano's external size can make or break your day. Let's break down each wheelbase and roof configuration:
Model-by-Model Exterior Sizes
L1 (short): Compact for its class. Length: 5,048 mm, Wheelbase: 3,182 mm.
L2 (medium): Adds 500 mm in load length while retaining manoeuvrability.
L3 (long): Extra length and options for both high (H2) and super high (H3) roofs; overall length jumps to 6,198 mm.
L4 (extra-long): At 6,848 mm, it's one of the largest panel vans you can drive on a standard licence.
All Movanos (across the 2025 range) measure 2,070 mm wide excluding mirrors, or a substantial 2,470 mm with mirrors deployed — important info in narrow yards or historic towns.
Roof heights range from 2,307 mm (L1H1, FWD) up to 2,808 mm (L4H3, RWD). Generally, RWD versions are slightly taller, making them ideal for maximum internal height.
Door Openings
Side load door width increases from 1,050 mm (L1) to 1,270 mm (L2 and up). Rear doors are uniform at 1,577 mm wide and up to 1,820 mm tall, accommodating standard euro pallets or sizeable furniture.
Diagrams for Reference
Vauxhall Movano Side View L4H3 Movano in factory-finish white: side diagram with major exterior dimensions.
Vauxhall Movano Rear Rear view with both doors open — perfect for palleted deliveries.
Movano Interior Loadspace & Volume
Inside the Movano is where you'll find its true talent. The difference in usable load lengths is dramatic between L1 and L4 versions, and it's not just about the longest boards — the cubic volume offered will influence how many jobs you can take on a single run.
Load Lengths, Heights, and Practical Capacity
Model
Load Length (mm)
Max Height FWD (mm)
Max Height RWD (mm)
Max Width (mm)
Between Arches (mm)
Max Volume (cu m)
L1H1/H2 (FWD)
2,583
1,700/1,894
–
1,765
1,380
7.8/8.6
L2H2/H3 (FWD)
3,083
1,894/2,144
–
1,765
1,380
10.8/12.3
L3H2/H3 (FWD)
3,733
1,894/2,144
–
1,765
1,380
13.0/14.8
L3H2/H3 (RWD)
3,733
–
1,798/2,048
1,765
1,380
13.0/14.8
L4H2/H3 (RWD)
4,383
–
1,798/2,048
1,765
1,380
14.9/17.0
What Can You Fit?
L1H1: Two Euro pallets or long tools, perfect for city couriers or mobile trades.
L2/L3: Three Euro pallets, full 8x4’ timber sheets, even tall wardrobes.
L4H3: Full removal van capability — three Euro pallets with room to spare, generous headroom for oversize items.
The width between wheelarches (1,380 mm) is enough for a standard UK/EU pallet across the floor. All versions offer flat load bays for easy stacking.
Payload, Weight, and Towing Explained
Choosing a van is often about how much you can haul legally and safely. The Movano range is clear leader in payload and towing flexibility.
Gross Vehicle Weight (GVW) and Payload by Variant
Model
GVW (kg)
Payload (kg)
L1H1 (FWD)
2,800 / 3,300 / 3,500
920 / 1,420 / 1,620
L2H2 (FWD)
3,300 / 3,500
1,329 / 1,529
L3H2 (FWD)
3,500
1,431
L3H2 (RWD)
3,500 / 4,500
1,203 / 2,148
L4H3 (RWD)
3,500 / 4,500
1,157 / 2,037
The RWD options, with up to 4,500 kg GVW, support payloads exceeding 2,100 kg — a genuinely rare offering in 2025's 3.5-tonne van segment.
Towing: Most Movanos can legally tow 2,500-3,000 kg braked trailers, depending on engine and chassis. Always check manufacturer specifics before pairing with a trailer.
Movano vs Main Competitors (Sprinter, Transit, Master)
Large van buyers often compare Movano against key rivals like the Mercedes Sprinter, Ford Transit, and Renault Master. Here’s how the stats shape up:
Movano L4H3
Sprinter L4H3
Transit L4H3
Master L4H3
Ext. Length (mm)
6,848
7,367
6,704
6,848
Ext. Height (mm)
2,808
2,827
2,788
2,749
Load Length (mm)
4,383
4,807
4,217
4,383
Max Load Vol (m³)
17.0
17.0
15.1
17.0
Max Payload (kg)
2,037
2,373
2,122
1,904
The Movano matches or exceeds key specifications in most areas, making it an appealing value proposition — especially for those who don’t need the extra 500 mm of exterior length the Sprinter brings.
Short, hands-on reviews for each rival are available in our van comparison section.
Buying Advice – Which Movano is Best for You?
Your business needs determine your choice. Here are some recommendations based on real applications:
City work or parcel delivery: Pick the L1H1 or L1H2. Easier to park, turn, and cheaper to run.
Builders or service engineers: L2H2 hits a sweet spot between usable space and ease of driving.
Heaviest loads (tools, building supplies): L3H2 or L4H3 with RWD and 4,500 kg GVW.
Removals or oversized loads: L4H3. Maximum interior space and headroom, with high payload for large or awkward jobs.
FWD vs RWD
FWD means lower load sill, lighter unladen weight, and is better in town.
RWD offers superior traction when fully laden, more towing capacity, and higher GVW options, but with slightly higher purchase prices and running costs.
Movano FAQs – Size and Practicality Questions Answered
Can I stand up in an L2H2 Movano? Yes. The standing height is 1,894 mm (FWD) or 1,798 mm (RWD), so most adults can stand upright comfortably — even with work boots and a racking system.
Is the Movano the biggest van you can drive on a car licence? The largest 3,500 kg GVW models (all L1–L4) remain within standard car licence restrictions. For the RWD 4,500 kg versions, you'll need a C1 licence.
How wide is the Movano between the arches? Across all models, the internal width between the wheelarches is 1,380 mm — more than enough for standard euro pallets, but check your load dimensions if you regularly move wider items.
Do payloads differ much between front and rear-wheel drive? RWD versions support higher absolute payloads (up to 2,148 kg on L3H2 RWD), yet the unladen weight and running cost may increase. Pick RWD if your work involves maximum loads or heavy towing.
Are all Movano sizes available with either FWD or RWD? L1 and L2 sizes are available as FWD only. L3 and L4 are available as RWD, with higher GVW and payload ratings.
Jamie Harris is a commercial vehicle analyst and van specialist, known for his clear and practical advice to fleet buyers and small businesses across the UK. Over the past 12 years, Jamie has reviewed hundreds of vans—including every version of the Vauxhall Movano—focusing on real-world usability, dimensions, and payloads.
